Bolt Cutters

Bolt Cutters by MCC, Japan

Bolt Cutters
  • Most popular and widely used with all purpose cuts adaptable from soft to medium hard materials. These bolt cutters give quick and easy cut of rods and bolts. Blades are drop forged from alloy tool steel and carefully heat-treated for maximum strength and wear resistance. All tubular handles except 300mm with ductile handles.
  • 300mm-450mm clipper cut and 600mm-1050mm center cut.
  • 350mm & 450mm center cut available at buyer’s request.
Model No. Size
mm(inch)
Max Capacity(Dia.)/Metal Hardness Weight
Kg
Spare Blade
No.
80 HRB Rod 20 HRB Rod 36 HRB Rod
BC-0730 300 (12") 5 ( 3 /16") 5 ( 3 /16") 3 ( 7 /64") 0.65 BCE0030
BC-0735 350 (14") 6 ( 1/4") 6 ( 1/4") 5 ( 3 /16") 0.95 BCE0035
BC-0745 450 (18") 8 ( 5 /16") 8 ( 5 /16") 6 ( 1/4") 1.45 BCE0045
BC-0760 600 (24") 10 ( 3 /8") 10 ( 3 /8") 8 ( 5 /16") 2.50 BCE0060
BC-0775 750 (30") 13 ( 1 /2") 13 ( 1 /2") 10 ( 3 /8") 3.85 BCE0075
BC-0790 900 (36") 15 ( 5 /8") 14 ( 9 /16") 11 ( 14 /32") 5.90 BCE0090
BC-0710 1050 (42") 18 ( 11 /16") 16 ( 5 /9") 13 ( 1 /2") 8.05 BCE0010

*Wear safety glasses at all times. Warn your fellow workers of flying metal to protect those in the area. Do not twist or pry with tool while cutting

Heavy Duty Bolt Cutters by MCC, Japan

Heavy Duty Bolt Cutters
  • Highest grade special high carbon alloy steel with special heat treatment to maximize its tensile strength for daily use on hardest material cutting such as hard chains,locks, and padlock.
  • The cutting edge shape is uniquely designed for hard materials cutting to withstand toughest work.
  • Silver color lockplate for identification.
  • Lighter weight, great strength on steel tubular handles on 18″ to 36″ bolt cutters.
  • Made in Japan
Model No. Size
mm(inch)
Max Capacity(Dia.) Weight
Kg
Spare Blade
No.
31 HRB Rod 40 HRB Rod
BC-0945 450 (18") 6 ( 1 /4") 6 ( 1 /4") 1.45 BCE0945
BC-0960 600 (24") 8 ( 5/16") 8 ( 5/16") 2.50 BCE0960
BC-0975 750 (30") 10 ( 3 /8") 9 ( 11 /32") 3.85 BCE0975
BC-0990 900 (36") 12 ( 15 /32") 10 ( 3 /8") 5.90 BCE0990

Ratchet Action Bolt Cutter by MCC, Japan

Ratchet Action Bolt Cutter
  • Drop forged from selected alloy tool steel and carefully heat-treated for durability. Ratchet action and special shape of cutting edges assure much easier cut of soft steel bar or reinforcing rod than conventional bolt cutters. Coarse rods or bars can be cut by the bottom part of edge and finer ones by the top of edge.
Model No. Size
mm(inch)
Max Capacity(Dia.)/Metal Hardness Weight
Kg
Spare Blade
No.
80 HRB Rod 20 HRB Rod
RBC-3213 785 (31") 13 ( 1 /2") 11 ( 14 /32") 4.70 RBCE3213

Bolt Cutters, Aluminum Handles by MCC, Japan

Bolt Cutters, Aluminum Handles
  • 30% lighter weight than steel handle type, which makes it easier to carry and work on through extended cutting time.
  • Improve safety level for overhead cutting or high work place by minimizing your tool weigh.
  • Clipper Cut design on 12″ allows you flush cuts that are close to workpiece.
  • Center Cut design on 14″ & 18″ prolong the life span of the blade.
  • The Jaw Blade is identical to the “Standard Model”.
  • Introducing the most compact size 250mm keeping the cutting capacity same as 300mm. Great performance for professionals.
  • Made in Japan
Model No. Size
mm(inch)
Max Capacity(Dia.) Weight
Kg
Spare Blade
No.
80 HRB Rod 36 HRB Rod
BCA-250 250 (10") 5 ( 3 /16") 3 ( 7 /64") 0.38 BCE0025
BC-AL30 300 (12") 5 ( 3 /16") 3 ( 7/64") 0.48 BCE0030
BCA-350 350 (14") 6 ( 1 /4") 4 ( 5 /32") 0.67 BCE0035
BCA-450 450 (18") 8 ( 5 /16") 6 ( 1 /4") 1.08 BCE0045

Angled Head Bolt Cutters by MCC, Japan

Angled Head Bolt Cutters
  • Made from carbon tool steel and carefully heat treated. Cutting edges are offset 30゜from handles to cut materials on surface. Blades interchangeable with bolt cutters.
Model No. Size
mm(inch)
Max Capacity(Dia.)
80 HRB Rod
Weight
Kg
Spare Blade
No.
AC-0030 300 (12") 5 ( 1 /4") 0.65 ACE0030
AC-0045 450 (18") 7 ( 5 /16") 1.45 ACE0045
AC-0060 600 (24") 10 (3 /8") 2.85 ACE0060
